Zeiss Xradia microXCT-400
Device ID: 000000D47
GENERAL DETAILS
Device ID000000D47
ModelXradia microXCT-400
ManufacturerZeiss
ModalityX-Ray Computed Tomography (CT/microCT)
DescriptionmicroXCT utilizes cone-beam acquisition: data for up to 2000 slices covering an entire volume can be acquired in a single rotation. Because the height of the scan field is equivalent to its width, high-aspect-ratio specimens must generally be scanned in contiguous parts and the parts then matched together. The microXCT scanner features a Hamamatsu X-ray source capable of energies from 40 to 150 kV. The detectors are mounted on microscope objectives with magnifications ranging from 0.4X to 40X; the former yields a field of view of ~55 mm, whereas the latter yields ~0.5 mm. Thus the spatial resolution for the microXCT ranges from ~55 µm to less than 1 µm. The microXCT scanner also offers the advantage of enhanced phase contrast to better image materials with low mean atomic numbers such as soft tissues and polymers.
MorphoSource ARK
647 MEDIA IMAGED BY DEVICE
Zeiss Xradia microXCT-400
Device ID: 000000D47
GENERAL DETAILS
Device ID
000000D47
Model
Xradia microXCT-400
Manufacturer
Zeiss
Modality
X-Ray Computed Tomography (CT/microCT)
Description
microXCT utilizes cone-beam acquisition: data for up to 2000 slices covering an entire volume can be acquired in a single rotation. Because the height of the scan field is equivalent to its width, high-aspect-ratio specimens must generally be scanned in contiguous parts and the parts then matched together. The microXCT scanner features a Hamamatsu X-ray source capable of energies from 40 to 150 kV. The detectors are mounted on microscope objectives with magnifications ranging from 0.4X to 40X; the former yields a field of view of ~55 mm, whereas the latter yields ~0.5 mm. Thus the spatial resolution for the microXCT ranges from ~55 µm to less than 1 µm. The microXCT scanner also offers the advantage of enhanced phase contrast to better image materials with low mean atomic numbers such as soft tissues and polymers.
MorphoSource ARK
